Sega Let's Go Jungle User Manual

ASSEMBLY AND INSTALLATION
27
6
6
Attach the mat brackets on the left and right
sides where the Main Cabinet and Seat Cabi-
netoorsjoinandxtheminplaceusingfour
hexagonbolts.Theboltshaveatandspring
washers attached.
The mat brackets are different for the left and
right sides.
FIG. 6-5d
FIG. 6-5e MAT BRACKETS
HEXAGON BOLT (4 ea.), chrome
M6x20, w/at & spring washers
MAT BRACKET L
MAT BRACKET R (other side)
