ASSEMBLY AND INSTALLATION
31
6
3
Check to ensure that the curtain opens and
closes smoothly.
1
There are six plastic rings along the top of the
curtain. Hang the ring on the edge that will be
closesttothescreenfromthexedhookonthe
curtain rail.
Attach the curtain. The curtain for the left side and right
side is different. Hang the curtains so that the printed
side is on the outside and diagonal cut along the bottom
is toward the seats.
FIG. 6-8a
FIG. 6-8b
FIG. 6-8c
FIG. 6-8d
2
Hang the other rings from the sliders on the cur-
tain rail. Open the ring, pass it through the ring
on the slider, and then reconnect the concave /
convex parts on the open ring. Hang each ring
onto a slider.
8 ATTACHING THE CURTAIN (Optional)
PRINTED SIDE
DIAGONAL CUT
To Next Page
