ASSEMBLY AND INSTALLATION
17
6
Tools Required for Assembly Operation
- Philips screwdriver (for M4, M6 screws)
- A 7, 10 millimeter socket wrench or hexagonal screwdriver (for M4, M6 hexagon bolts and nuts)
- A 3 millimeter hexagonal bar wrench or screwdriver - Flashlight or other supplementary lighting
- A 24 millimeter spanner (Adjustable spanner) - Stepladder
- Master key (accessory)
The assembly of this product is performed in the following 14 steps.
1
CONNECTION OF THE DLP AND MAIN CABINET
2 ATTACHING THE SIDE CLOTH
3 ATTACHING THE TOP BOARD
4 ATTACHING THE BILLBOARD BOX
5 CONNECTION OF THE SEAT CABINET
6 ATTACHING HARNESS COVER S
7 ATTACHING THE BILLBOARD
8 ATTACHING THE CURTAIN
9 INSTALLATION OF THE FLUORESCENT BULBS
10 FIXATION TO INSTALLATION SITE
11 CONNECTING THE DVD DRIVE (PREPARATION FOR INSTALLATION)
12 CONNECTION OF POWER AND GROUND
13 ENGAGEMENT OF POWER SUPPLY (SOFTWARE INSTALLATION)
14 CONFIRMATION OF ASSEMBLY
3mm
24mm
To Next Page
