9-3b OUTPUT TEST
The condition of each output device can be checked. Periodically check the condition of each output device on this
screen. Conditions are normal if each device operates and yields output as indicated below.
<Operation>
1
Press the SERVICE Button and move the cursor to the item (output device) you want to test.
2
Whenever the TEST Button is pressed, the display on the right side of the item goes from OFF to ON and
the selected output device operates. Conrm that the device operates normally.
3
Press the SERVICE Button and move the cursor to EXIT.
4
When the TEST Button is pressed, the game test mode menu screen reappears.
<Menu Explanation>
GUN MOTOR: When ON the motor will operate and the controller will vibrate, when OFF it will stop.
SENSOR: Will continue to switch between ON and OFF when the motor is in operation.
START LAMP: Start lamp will turn on when ON and off when OFF.
ROOM LAMP: Main cabinet ceiling orescent lamp will turn on when ON and off when OFF.
COIN LAMP: Coin insert slot lamp will turn on when ON and off when OFF.
EXIT: Game Test Menu screen reappears.
FIG. 9-3b OUTPUT TEST Screen
OUTPUT TEST
1P GUN MOTOR OFF SENSOR ON
1P START LAMP OFF
2P GUN MOTOR OFF SENSOR ON
2P START LAMP OFF
ROOM LAMP OFF
COIN LAMP OFF
-> EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
