12
PART DESCRIPTIONS
4
(Width x Depth x Height) (Weight)
Main Cabinet 1,532 mm × 1,237 mm × 1,980 mm 234.5 kg
Seat Cabinet 1,532 mm × 1,016 mm × 1,800 mm 149 kg
DLP 1,500 mm × 533 mm × 1,705 mm 150 kg
Billboard 1,240 mm × 834 mm × 355 mm 29.5 kg
- In this product, the DLP cabinet housing the 62 inch projector is termed the “DLP.”
- Facing the projector screen, the left side is the 1P seat and the right side is the 2P seat.
FIG. 4 Name of Each Part
TABLE 4 Major Measurements of Each Unit Upon Purchase
PART DESCRIPTIONS
4
FLUORESCENT BULBS
BILLBOARD BOX
BILLBOARD
SEE B
CURTAIN
SIDE CLOTH
FLUORESCENT LIGHT
SEAT CABINET
PROJECTOR SCREEN
MAIN CABINET
SPEAKER
1P SIDE START BUTTON
LEFT SEAT SIDE
2P SIDE START BUTTON
RIGHT SEAT SIDE
2P SIDE CONTROL UNIT
COIN CHUTE DOOR
CASH BOX DOOR
FRONT DOOR PCB
1P SIDE CONTROL UNIT
AC UNIT
DLP
RIGHT SEAT SIDE
LEFT SEAT SIDE
