FIG. 6-14b OUTPUT TEST Screen
6
Output Test
When“OUTPUTTEST”hasbeenselectedonthegametestmodemenu,thescreenfortestinglampsand
other output devices appears.
If each output device operates properly, the output device and its wiring connections are normal. (See 9-3b.)
FIG. 6-14c GUN CALIBRATION Screen
7
Calibration
Conrmthattheoperabilityofcontrolunitdonotpresentanyhindrancestoplay.Calibrationisadjusted
when the product is shipped from the factory but it might need to be adjusted again because of vibrations
during transport, etc.
Ifsuchthingsasoperabilityarenotsatisfactory,select“GUNCALIBRATION”onthegametestmode
menu and check and adjust settings. (See 9-3c.)
Conduct the aforesaid tests when performing routine tests each month.
OUTPUT TEST
1P GUN MOTOR OFF SENSOR ON
1P START LAMP OFF
2P GUN MOTOR OFF SENSOR ON
2P START LAMP OFF
ROOM LAMP OFF
COIN LAMP OFF
-> EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
GUN CALIBRATION
CALIBRATION START
-> EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
