Sega Let's Go Jungle User Manual

20
ASSEMBLY AND INSTALLATION
6
7
Attach the DLP joint upper to the connecting
section on the cabinet roof. Fix it with three
hexagon bolts on the DLP side. The bolts have
atandspringwashersattached.
8
Fix the DLP joint upper to the Main Cabinet us-
ingthreehexagonbolts.Theboltshaveatand
spring washers attached.
FIG. 6-1g
DLP JOINT UPPER
FIG. 6-1h
M6x20, w/at & spring washers
DLP JOINT UPPER
HEXAGON BOLT (3), black
M6x20, w/at & spring washers
HEXAGON BOLT (3), black
