SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
155
Programming via Rockwell controller
This section is intended only for Rockwell users (RF680R/RF685R).
This section describes the programming and configuration of the RF680R and RF685R
readers via a Rockwell controller. With the described functions, you can read out and write
transponder data via the readers.
Importing add-on instructions
To program Ident systems using the Studio 5000 Logix Designer, you require add-on
instructions. You will find the add-on instructions on the DVD supplied with the readers.
The Studio 5000 Logix Designer was started and a project was created.
Follow the steps below to import the add-on instructions into the Studio 5000 Logix Designer:
1. Copy the installation file (*.l5x) locally to your PC.
You will find the file on the DVD supplied with the product.
2. Open the Studio 5000 Logix Designer and change to the project view.
3. Right-click on the folder "Add-on Instructions" in the "Controller Organizer" area.
4. In the shortcut menu, select the menu command "Import Add-On Instruction...".
The dialog "Import Add-On Instruction" opens.
5. Go to the installation file (*.lx5) and select it.
6. Confirm your entry with "OK".
Result: The add-on instructions are imported into the Studio 5000 Logix Designer:
