Appendix
A.3 Command and acknowledgement frames
SIMATIC RF650R/RF680R/RF685R
336 Configuration Manual, 03/2018, C79000-G8976-C386-06
A.3.10
GET-BLACKLIST
The entire TagIDs are read out from the black list.
Table A- 26 Command
Byte
0, 1 2, 3 4 5 6, 7 8 9 10 11
Mean-
ing
DBL SN CC CI TDB DBN_H DBN_L DBL --
Value
78 -- 'l' 'U' 1 0 1 -- 0
Byte
12
13
14, 15
16, 17
18 ... 21
22, 23
24, 25
26
27 ... 88
Mean-
ing
SOURCE -- -- -- -- -- -- -- --
Value
0
0
0
0
0
0
0
--
--
Table A- 27 Reply
Byte
0, 1
2, 3
4
5
6, 7
8
9
10
11 ... 239
Mean-
ing
DBL SN CC STATUS TDB DBN_H DBN_L DBL DATA
Value
0
--
'l'
xx
--
--
1
0
--
Table A- 28 Description of the bytes
Byte
Description
12
Reserved (value = 0)
