Siemens SIMATIC RF650R User Manual

Programming via XML interface
10.3 XML commands
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
241
Parameter
Type
Values
Description
value_
filterDataAvailable
Fixed values True
False
Optional
Indicates whether or not a filter criteri-
on was received.
• True:
No problem All the data was read
or there was no filter set.
• False:
Data could not be read.
value_data Hexadecimal
value
0...9, A...F
-- Data that should be read. Each byte is
represented by two hexadecimal char-
acters.
Example:
The byte sequence "0x12, 0x34, 0xA3"
is represented as the character string
"1234A3" in the "value_data" parame-
ter.
"value_dataLength" is 3 in this exam-
ple.
If the transponder is identified but the
data cannot be read (e.g. if the tran-
sponder has no user memory as re-
quired), this field remains empty.
"value_success" is then set to "False".
10.3.3.8
writeTagMemory
This command writes data to the requested transponder. If no EPC-ID is made available or
detected, the command is executed with all the transponders recognized from the read point.
Note
If no EPC
-ID is specified, the results are influenced by all the set filter mechanisms (refer to
the section "
The "Settings - Filters" menu item (Page 68)"). Then in the reply frame, only the
transponders that were not filtered out appear. If an EPC
-ID is specified, the data filter has
no effect.
The reply frame contains the IDs of all identified transponders. A flag for each transponder
indicates whether or not the command was successful for this transponder.
If no transponder was identified, a negative reply is returned.
