Siemens SIMATIC RF650R User Manual

Appendix
A.3 Command and acknowledgement frames
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
327
A.3
Command and acknowledgement frames
This section is intended for both S7 and Rockwell users.
The communications principle of the Ident blocks described in this manual is based on the
"Proxy Ident Function Block" specification. If you want to program your own blocks for
configuring your RF680R/RF685R readers, make sure that they are created so that they
conform to this specification.
You can obtain the specification of the "Proxy Ident Function Block" from the PROFIBUS
User Organization. You will also find further information in the manual "Ident Profile and
Ident Blocks, Standard Function for RFID systems".
NOTICE
Deviations from the specification
Some of the command frames of the specification were adapted and differ from those listed
in the specification. These adapted command frames as well as the unchanged command
frames used are described in the following sections.
A.3.1
General structure of the adapted commend frame
Table A- 2 Command for SIMATIC readers
Byte
0, 1
2, 3
4
5 *
6, 7
8
9
10
11
Mean-
ing
DBL SN CC CI TDB DBN_H DBN_L DBL MODE
Value
--
--
--
'-'
--
--
1
--
0
Byte
12
13
14, 15
16, 17
18 ... 21
22, 23
24, 25
26
27 ... 88
Mean-
ing
SOURCE BANK ADDRES
S
LENGTH PSWD ACTION MASK IDLENGT
H
EPC-ID
Value
--
--
--
--
--
--
--
--
--
* Identifies a chained command in the CI byte:
-
Uppercase letters (A - Z): no chained command or end of the command chain
- Lowercase letter (a - z): Chained command
