Programming via XML interface
10.4 XML EventReports
SIMATIC RF650R/RF680R/RF685R
272 Configuration Manual, 03/2018, C79000-G8976-C386-06
Parameter
Type
Values
Description
value_rSSI Decimal value
0...9
0...255 RSSI value
This is a value without a unit and with-
out direct reference to the power
strength.
value_channel Decimal value
0...9
1...50 Optional
Channel number on which the tran-
sponder was detected.
value_power Decimal value
0...9
0, 5.00...33.00 Optional
Used radiated power of the antenna in
[dB]
Increment: 0.25 dB
value_polarization Fixed values Circular
Vertical
Horizontal
Unknown
Polarization of the antenna.
With external antennas always un-
known.
10.4.1.3
ioEventReport
An I/O event report signals changes at an input or output.
In the WBM, the sending of I/O events can be configured. You will find more information on
events in the section "The "Settings - Communication" menu item (Page 74)".
Report
<frame>
<report>
<id> value_id </id>
<ioer>
<io>
<ioName> value_ioName </ioName>
<ioEvent> value_ioEvent </ioEvent>
<utcTime> value_utcTime </utcTime>
</io>
<io> // opt
…
</io> // opt
</ioer>
</report>
</frame>
// opt → Optional: Line can be omitted.
