Service and maintenance
12.2 Error messages
SIMATIC RF650R/RF680R/RF685R
288 Configuration Manual, 03/2018, C79000-G8976-C386-06
Diagnostics using Studio 5000 Logix Designer
This section is intended only for users of Rockwell controllers (RF680R/RF685R).
You will find information on diagnostics using the Studio 5000 Logix Designer in the Studio
5000 Logix Designer manual.
You have the following options for error analysis of the modules:
● Via the LED status display of the reader
for RF680R/RF685R
● Via XML error messages
for RF650R/RF680R/RF685R
You will find more information on XML error messages in the section "Interrupts
(Page 274)".
● Via OPC UA error messages
for RF680R/RF685R
● using the WBM
for RF650R/RF680R/RF685R
These alternative methods are described below.
