Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
97
7.3.12
The "Diagnostics - Messages" menu item
In the "Diagnostics - Messages" menu item, all messages of the WBM (e.g. transfer errors)
are displayed.
Figure 7-20 The "Diagnostics - Messages" menu item
All the error messages and warnings displayed in the log bar are automatically entered in the
messages list.
The entries contain the following properties:
Table 7- 27 Displayed properties of the messages
Property
Description
No
Chronological numbering of the messages.
Date/time
Time stamp of when the warning or error message occurred.
Menu
Menu item that was selected when the message occurred.
Type Type of message
Message
Text of the message
Comment Explanation of the message text.
