A.3 Command and acknowledgement frames
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
335
A.3.9
EDIT-BLACKLIST
The black list is processed. The current transponder can be added, all identified
transponders added, individual transponders deleted or all transponders deleted.
Table A- 23 Command
Byte
0, 1 2, 3 4 5 6, 7 8 9 10 11
Mean-
ing
DBL SN CC CI TDB DBN_H DBN_L DBL MODE
Value
78 -- 'z' 'U' 1 0 1 -- xx
Byte
12 13 14, 15 16, 17 18 ... 21 22, 23 24, 25 26 27 ... 88
Mean-
ing
SOURCE -- -- -- -- -- -- IDLENGT
H
EPC-ID
Value
0
0
0
0
0
0
0
xx
xx
Table A- 24 Reply
Byte
0, 1
2, 3
4
5
6, 7
8
9
10
Meaning
DBL
SN
CC
STATUS
TDB
DBN_H
DBN_L
DBL
Value
0
--
'z'
xx
1
--
1
0
Table A- 25 Description of the bytes
Byte
Description
11 Mode:
• 0x00 = add TagID
• 0x01 = add all "OBSERVED" transponders
• 0x02 = delete TagID
• 0x03 = delete all
12
Reserved (value = 0)
26 Length of the EPC ID:
• 0x00 = not addressed
27 ... 88
Buffer for up to 62 bytes EPC-ID
