Programming via XML interface
10.3 XML commands
SIMATIC RF650R/RF680R/RF685R
202 Configuration Manual, 03/2018, C79000-G8976-C386-06
Parameter
Parameter
Type
Values
Description
value_id Decimal value
0...9
0...4294967295 Unique command identifier
value_configID Alphanumeric text -- Unique identifier of the transferred
configuration
10.3.2.4
getActiveConfiguration
This command requests the active parameters with which the reader is currently working as
a configuration file from the reader.
Note that the values may differ from the stored values.
Note that the reply frame of the reader can take up to 20 seconds.
Command
<frame>
<cmd>
<id> value_id </id>
<getActiveConfiguration/>
</cmd>
</frame>
Reply
<frame>
<reply>
<id> value_id </id>
<resultCode> 0 </resultCode>
<getActiveConfiguration>
<returnValue>
<configID> value_configID </configID>
<configData>
<![CDATA[value_configData]]>
</configData>
</returnValue>
</getActiveConfiguration>
</reply>
</frame>
The error codes for negative replies ("resultCode" ≠ 0) are described in the section "Negative
XML replies (Page 263)".
