5-36
3. Switch check (1)
Page 2 Address 80
*1: Refer to “Switch check (2)” and “Switch check (5)”.
*2: MVC-CD300 model only.
Using method:
1) Select page: 2, address: 80.
2) By discriminating the bit value of display data, the state of the
switches can be discriminated.
4. Switch check (2)
Page 2 Address 86
*3: Refer to “Switch check (1)” and “Switch check (5)”.
Using method:
1) Select page: 2, address: 86.
2) By discriminating the bit value of display data, the Mode dial
position can be discriminated.
5. Switch check (3)
Page 2 Address 84
Using method:
1) Select page: 2, address: 84.
2) By discriminating the lower digit of the data, the rotation of
the control dial can be discriminated.
Bit
0
1
2
3
4
5
Function
Power switch (XPOWER ON)
(Control switch block (ZK-503))
Mode dial (XPB ON) *1
(Control switch block (ZK-503))
Lens cap switch *2
(XLENS CAP OPEN)(TK-61 board S503)
Shutter button (XSHTR ON)
(Control switch block (RK-503))
Shutter button (XAE LOCK ON)
(Control switch block (RK-503))
Lid open/close switch
(XLID OPEN SW)(JK-208 board S101,103)
When bit value = 1
Power switch off
Except PLAY
Off
(Without Lens cap)
Off
Off
On
(Lid close)
When bit value = 0
Power switch on
PLAY ( )
On
(With Lens cap)
On
On
Off
(Lid open)
Bit
6
Function
Mode dial (XSETUP) *3
(Control switch block (ZK-503))
When bit value = 1
Except SETUP
When bit value = 0
SETUP
Jog dial
(Control switch block (ZK-503))
When rotated upward.
When rotated downward.
Lower digit of the data
...
→0→4→C→8→0→
...
...
→0→8→C→4→0→
...
To Next Page
