2-5
2-4. CABINET (FRONT) ASSEMBLY (TK-61 BOARD),
CONTROL SWITCH BLOCK (RL-503)
JK-
208
C
D
-
333
SY-67
C
D
-
334
1 Two screws
(M 1.7 × 2),
lock ace, P2
2 Two claws
Control switch block
(RL-503) (6P)
5 Two tapping
screws (B 1.7 × 3.5)
6 Microphone holder
assembly
4 Microphone
sheet
7 Microphone cushion
8 Microphone
9 Retainer
sheet
metal
3 Rear sheet
metal (upper)
1 Two precision
screws
(DIA 1.7 × 4)
3 Two precision
screws
(DIA 1.7 × 4)
TK-61 board
CD-334 board
CD-333 board
2 LED cap
5 Tape (A)
6 TK-61 board,
FP-369 flexible
board
FP-369 flexible
board (5P)
4 FP-370 flexible
board (5P),
LED
3 Cabinet (front) assembly
2 Control switch
block (RL-503)
1 Two precision
screws
(DIA 1.7 × 4)
AC IN
AC power
adaptor
CPC-9 jig
(J-6082-393-C)
1
18
Adjustment remote
commander (RM-95)
(CD300)
(CD200)
FP-364 flexible
board (70P)
Lens block assembly
Lens block assembly
[CD-333/334, TK-61 BOARDS SERVICE POSITION]
