5-7
1-2-2. Initializing the B, E, F, 7, 9 Page Data
1. Initializing the B, E, F, 7, 9 Page Data
Note1: If “Initializing the B, E, F, 7, 9 Page Data” is performed,
all data of the B page, E page, F page 7 page and 9 page
will be initialized. (It is impossible to initialize a single
page.)
Note2: If the B, E, F, 7, 9 Page data has been initialized,
“Modification of B, E, F, 7, 9 Page Data” and following
adjustments need to be performed again.
1) Video system adjustments
2) Camera system adjustments
Adjusting page F
Adjusting Address 10 to FF
Adjusting page 7
Adjusting Address 00 to FF
Adjusting page 9
Adjusting Address 00 to FF
Adjusting page E
Adjusting Address 00 to FF
Adjusting page B
Adjusting Address 00 to FF
Initializing Method:
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 6 03 Set the following data.
12: MVC-CD200
11: MVC-CD300
3 6 00 2D Set the data.
4 6 01 2D Set the data, and press PAUSE
button.
5 6 02 Check that the data changes to
“01”.
6 Perform “Modification of B, E, F,
7, 9 Page Data”.
2. Modification of B, E, F, 7, 9 Page Data
If the B, E, F, 7, 9 Page data has been initialized, change the data of
the “Fixed data-2” address shown in the following tables by manual
input.
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note: If copy the data built in the different model, the camera may
not operate.
3) When changing the data, press the PAUSE button of the
adjustment remote commander each time when setting new
data to write the data in the non-volatile memory.
4) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
Processing after Completing Modification of B, E, F, 7, 9 Page
data
Order Page
Address
Data Procedure
1 2 00 29 Set the data.
2 2 01 29 Set the data, and press PAUSE
button.
3. F Page Table
Note: Fixed data-1: Initialized data. (Refer to “1. Initializing the B, E, F,
7, 9 Page Data”.)
Fixed data-2: Modified data. (Refer to “2. Modification of B, E, F,
7, 9 Page Data”.)
10 to 13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30 to 33
34
35
36 to 39
3A
3B
3C
3D
3E
3F
40
41
42
43
44
45
46
47
48
49 to 4C
4D
4E
12
A8
18
C5
12
C9
00
00
00
00
41
00
20
20
20
44
0A
00
B2
63
2E
00
00
00
00
00
69
84
15
78
2F
37
40
D0
86
41
03
E9
63
83
D5
FE
73
45
28
6E
Fixed data-1
Flange back adj.
Light value adj.
F No. compensation
HALL adj. (MVC-CD200)
Fixed data-1 (MVC-CD300)
Fixed data-1
HALL adj. (MVC-CD200)
Fixed data-1 (MVC-CD300)
Fixed data-1
AWB standard data input
Fixed data-1
Auto white balance adj.
Color reproduction adj.
Fixed data-1
Strobe adj.
33
48
DA
DF
13
C0
00
00
00
00
00
00
20
20
BA
46
0A
00
85
B0
94
00
00
00
00
00
2F
37
40
D0
B5
43
03
E9
63
83
D5
FE
73
45
28
6E
Address Remark
Initial value
CD200CD300
