Sony MVC-CD200 Service Manual

6-9
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model.
HK : Hong Kong model.
AUS : Australian model.
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CN : Chinese model.
KR : Korea model.
J : Japanese model.
CD-334
A-7074-840-A CD-334 BOARD, COMPLETE (CD300)
******************************
A-7074-843-A CD-333 BOARD, COMPLETE (CD200)
******************************
(Ref.No.;1000 Series)
(IC101 and IC401 are not included in this COMPLETE BOARD)
< CAPACITOR >
C101 1-107-690-11 TANTAL. CHIP 6.8uF 20% 35V
(CD200)
C102 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
(CD200)
C103 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
(CD200)
C104 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(CD200)
C105 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
(CD200)
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(CD200)
C107 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(CD200)
C108 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(CD200)
C109 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(CD200)
C111 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
(CD200)
C201 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C202 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C203 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C204 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C205 1-164-876-11 CERAMIC CHIP 120PF 5% 16V
(CD300)
C206 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C208 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C209 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C210 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C211 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C212 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C213 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C214 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C215 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C216 1-164-876-11 CERAMIC CHIP 120PF 5% 16V
(CD300)
C217 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C218 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C219 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C220 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C221 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C222 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C223 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C224 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C225 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C226 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C227 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C228 1-107-690-11 TANTAL. CHIP 6.8uF 20% 35V
C229 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C230 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C231 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C302 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
(CD200)
C303 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(CD200)
C304 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(CD200)
C305 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
(CD200)
C306 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
(CD200)
C307 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C308 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C309 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C310 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C311 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C312 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(CD200)
C313 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
(CD200)
C314 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
(CD200)
C316 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(CD200)
C317 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(CD200)
C318 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(CD200)
C319 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(CD200)
C320 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(CD200)
C321 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
(CD200)
C322 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
CD-333
