AC IN
AC power
adaptor
Monitor TV
Tapping
screw (DIA1.7 × 5)
CPC-9 jig
(J-6082-393-C)
CPC lid
1
1
18
18
Adjustment remote
commander (RM-95)
Connect the remote
commander to either one.
[CONNECTION OF THE EQUIPMENT]
MVC-CD200/CD300
2-2. Cabinet (front) section
2-7. Stroboscope section (Flash unit)
CD-333/334, TK-61 boards service position
Flash unit service position
2-1. LCD section (PK-58 board)
2-5. Battery holder (JK-208 board)
2-6. SY-67 board
2-8. Base unit (DDX-G2100 complete assembly)
2-10. Function button (FS-83 board)
2-11. Solenoid plunger (Door lock/Stroboscope),
CD lock slider
2-9. Lid CD section
PK-58 board service position
SY-67, JK-208, CD-333/334 boards and
Camera section check service position
2-3. Lens section (CD-333/334 board)
2-4. Cabinet (front) assembly (TK-61 board),
Control switch block (RL-503)
2-12. Control switch block (ZK-503), Strap shaft
2-13. Mode knob, Power spring
FS-83 board and
Base unit (DDX-G2100 complete assembly)
check service position
MD-083 board service position
2-16. Disassembling procedure of MD-083 board
1
CN302
18
Refer to level 3
To Next Page
