5-17
6. F No. Standard Data Input
Compensate the unevenness of the iris meter sensitivity.
Mode Still (Auto ( ))
Subject Clear chart
(Color reproduction adjustment frame)
Adjustment Page F
Adjustment Address 29 to 2D
Note1: This adjustment should be carried out upon completion of “Data
Setting during Camera System Adjustments”.
Note2: Check that the data of page: 6, address: 02 is “00”. If not, to page:
6, address: 01, set data: 00, and press the PAUSE button.
Switch setting:
ZOOM....................................................................WIDE end
FOCUS............................................................ Manual (0.3m)
Adjusting method:
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 6 01 BB Set the data, and press PAUSE
button.
3 6 02 Check that the data changes to
“01”. (Note2)
Note3: The adjustment data will be automatically input to page: F, address:
29 to 2D.
Processing after Completing Adjustments:
Order Page
Address
Data Procedure
1 6 01 00 Set the data, and press PAUSE
button.
2 6 6C 00 Set the data.
3 0 01 00 Set the data.
7. Mechanical Shutter Adjustment
Adjust the period which the mechanical shutter is closed, and
compensate the exposure.
Mode Still (Auto ( ))
Subject Clear chart
(Color reproduction adjustment frame)
Measurement Point Display data of page: 6, address: AB
Measuring Instrument Adjustment remote commander
Adjustment Page F
Adjustment Address 5A, 6C to 7F, D4 to D8
Specified value 00
Note1: This adjustment should be carried out upon completion of “Data
Setting during Camera System Adjustments”.
Note2: Check that the data of page: 6, address: 02 is “00”. If not, to page:
6, address: 01, set data: 00, and press the PAUSE button.
Switch setting:
ZOOM.................................................................... WIDE end
FOCUS............................................................ Manual (0.3m)
Adjusting method:
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 6 01 AD Set the data, and press PAUSE
button.
3 6 02 Check that the data changes to
“01”. (Note2)
4 6 AB Check that the data is “00”.
Note3: The adjustment data will be automatically input to page: F, address:
5A, 6C to 7F, D4 to D8.
Processing after Completing Adjustments:
Order Page
Address
Data Procedure
1 6 01 00 Set the data, and press PAUSE
button.
2 0 01 00 Set the data.
