Sony MVC-CD200 Service Manual

2-3
2-2. CABINET (FRONT) SECTION
JK-208
SY-67
3 Two screws
(M 2 × 3.5)
qf FP-369 flexible board (5P)
qs FP-364 flexible
board (70P)
3 Ornamental ring
4 Accessory
shoe
2 Special (step)
screw (M 2)
1 Open the lid
CD section
5 Screw (M 2 × 4),
lock ace, P2
1 Screw (M 2 × 4),
lock ace, P2
1 Three screws (M 1.7 × 7)
qd Microphone
(2P)
6 Screw (M 2 × 4),
lock ace, P2
7 Screw (M 2 × 4),
lock ace, P2
9 Screw (M 2 × 4),
lock ace, P2
0 Two screws (M 2 × 4),
lock ace, P2
qg Control switch block
(RL-503) (6P)
qa BIB retainer
qh Cabinet (front) section,
Lens cabinet section,
Lens section
5 Lens
section
1 Screw (M 2 × 4),
lock ace, P2
3 Ornamental ring
5 Lens
section
6 Cabinet (front) section
4 Three screws (M 2 × 4),
lock ace, P2
4 Two screws (M 2 × 4),
lock ace, P2
2 Remove the lens cabinet assembly
in the direction of the arrow A.
2 Remove the lens cabinet assembly
in the direction of the arrow B.
4 Lens cabinet (H)
3 LC switch
2 Filter ring
A
B
6 Cabinet (front) section
(CD200)
(CD300)
8 Open the
BT lid
