Sony RM-IP500 User Manual

56
Recommended setting 3
This setting is recommended when actively using AE.
Assignment table
Function assignment menu item Setting of the unit ILME-FR7 assignable button function assignment
OPERATION > WHITE > WB MODE MEM.A T/T –
CONFIG > RM SETUP > AE CONFIG2 ALL –
CONFIG > SW ASSIGN > ASSIGN1 DISPLAY –
CONFIG > SW ASSIGN > ASSIGN2 ASSIGN 6 Base ISO/Sensitivity
CONFIG > SW ASSIGN > ASSIGN3 ASSIGN 9 ND Filter Position
CONFIG > SW ASSIGN > ASSIGN4 ASSIGN 7 Video Signal Monitor
CONFIG > SW ASSIGN > ASSIGN5 AUDIO LVL –
CONFIG > SW ASSIGN > ASSIGN6 AE LEVEL –
CONFIG > SW ASSIGN > IRIS KNOB ND FILTER –
Auto ND Filter +
Auto Iris +
AGC +
Auto Shutter
The orange labels indicate the buttons/
knobs used and their assigned
functions.
• All uppercase functions can be
assigned directly on this unit.
• Functions with mixed uppercase and
lowercase letters must be configured
on both this unit and the ILME-FR7.

Sony RM-IP500 Specifications

General

Interface	Wired
Product color	Black
Brand compatibility	Sony
Remote control proper use	-
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Built-in display	Yes
Maximum range	- m
I/O ports	RJ-45, D-Sub 15-pin, DC
Rechargeable	No
Harmonized System (HS) code	85299097

Weight and Dimensions

Depth	224.1 mm
Width	306 mm
Height	159.3 mm
Weight	2400 g
