Sony RM-IP500 User Manual

74
CAM POWER
Note
SRG-300SE, SRG-301SE, and SRG-201SE do not
switch to standby mode.
ZOOM
CAMERA FREQ
* The shutter speed is displayed in the status display
(page 62).
LCD BRIGHT
Adjusts the brightness of the LCD panel in five
increments, 1 (dark) to 5 (bright).
LAMP DIMMER
Adjusts the brightness of the LED buttons in five
increments, 1 (dark) to 5 (bright).
SW ASSIGN
ASSIGN 1 to ASSIGN 6
Assign functions to the ASSIGN 1 to ASSIGN 6
buttons of the unit.
IRIS KNOB
If the target camera is equipped with a variable
ND filter, you can assign a function to the IRIS
knob.
For details about function assignments to assign
bu
ttons, see “Assigning Functions to Assign
Buttons” (page 51).
DIRECTION
Sets the control direction of the joystick, ZOOM
lever, and FOCUS knob.
JOYSTICK PAN
JOYSTICK TILT
ZOOM LEVER
SHT Automatically adjusts the
exposure using the electronic
shutter speed. Adjust the ND
filter, iris, and gain manually.
Settings (Bold:
defa
ult value)
Description
EACH Only the target camera turns on/
off when using the CAM POWER
button.
ALL All cameras registered in the
camera table turn on/off when
using the CAM POWER button.
Settings (Bold:
default value)
Description
LEVER Controls the zoom of the target
camera using the ZOOM lever on
the lens control block.
JOYSTICK Controls the zoom of the target
camera using the ZOOM ring on
the joystick.
BOTH Controls the zoom of the target
camera using both the ZOOM
lever and the ZOOM ring on the
joystick.
Settings (Bold:
default value)
Description
59.94, 50, 23.98 Selects the frame rate for the
shutter speed displayed in the
menu. You can select from 59.94
[Hz], 50 [Hz], and 23.98 [Hz].
*
Settings (Bold:
default value)
Description
Settings (Bold:
default value)
Description
STANDARD Inclining the joystick to the right
pans the camera to the right.
Inclining to the left pans the
camera to the left.
REVERSE Inclining the joystick to the right
pans the camera to the left.
Inclining to the left pans the
camera to the right.
Settings (Bold:
default value)
Description
STANDARD Inclining the joystick forward tilts
the camera up. Inclining rearward
tilts the camera down.
REVERSE Inclining the joystick forward tilts
the camera down. Inclining
rearward tilts the camera up.
Settings (Bold:
default value)
Description
STANDARD Moving the ZOOM lever to the W
side (Wide) zooms out, and
moving to the T side (Tele) zooms
in.
REVERSE Moving the ZOOM lever to the W
side (Wide) zooms in, and moving
to the T side (Tele) zooms out.

Sony RM-IP500 Specifications

General

Interface	Wired
Product color	Black
Brand compatibility	Sony
Remote control proper use	-
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Built-in display	Yes
Maximum range	- m
I/O ports	RJ-45, D-Sub 15-pin, DC
Rechargeable	No
Harmonized System (HS) code	85299097

Weight and Dimensions

Depth	224.1 mm
Width	306 mm
Height	159.3 mm
Weight	2400 g
