Function of Buttons/Knobs in Each Block by Camera
Model
Cameras other than ILME-FR7
Yes: Supported
–: Not supported
Control block Button/knob Function Conditions
BRC-X1000/
H800/H780/
X400/X401
BRC-
H900
SRG
series
*1
Lens control
block
AE button Exposure mode
selection
When the button is on (lit): Full
auto.
When the button is off (not lit):
Fo
llows CONFIG >RM SETUP >AE
CONFIG setting in the RM menu.
Yes Yes Yes
*2
FOCUS
adjustment knob
Manual focus
adjustment
Enabled when the AUTO FOCUS
mode button is not lit.
Yes Yes Yes
O.P.A.F (one-
pu
sh auto focus)
button
One-push auto
focus adjustment
Enabled when the AUTO FOCUS
mode button is not lit.
Yes Yes Yes
IRIS knob Iris setting
ad
justment
Enabled when the AE button is
not lit, and CONFIG >RM SETUP
>AE CONFIG is set to MANUAL or
IRIS Pri in the RM menu.
Yes Yes Yes
Color
ad
justment
block
O.P.AWB (one-
push auto white
balance) button
One-push white
balance auto
adjustment
Enabled when OPERATION
>WHITE >WB MODE is set to ONE
PUSH in the RM menu.
Yes Yes Yes
O.P.ABB (one-
pu
sh auto black
balance) button
One-push black
balance auto
adjustment
Enabled when OPERATION
>BLACK >ABB MODE is set to ON
in the RM menu.
– Yes –
BARS button Toggle color bars
out
put on/off.
– Yes
*12
Yes –
ASSIGN 1 to
ASSIGN 3
bu
ttons
Toggle backlight
co
mpensation
on/off.
Enabled when the AE button is
lit.
Yes Yes
*3
Yes
Toggle flicker
co
mpensation
on/off.
Enabled when FLICKER CANCEL
>MODE is set to ON in the
camera menu.
Yes Yes –
Display the
st
atus of the iris,
gain, shutter
speed, and zoom
position.
– Yes Yes Yes
Toggle Clear
I
mage Zoom on/
off.
– Yes
*8 *12
– Yes
*11
Toggle the
teleconvertor
on/off.
– Yes
*8 *12
– –
Toggle preset
mod
e (MOD1-
TRCE, MOD2-
TRCE)
– Yes
*9
– –
R-WHITE knob/
B-WHI
TE knob
R gain and B gain
adjustment
Enabled when OPERATION
>WHITE >WB MODE is set to
MANUAL in the RM menu.
Yes Yes Yes
