Sony RM-IP500 User Manual

62
Checking Camera
Settings Status (Status
Display)
Press an assign button (ASSIGN 1 to ASSIGN 3)
with the camera status display function
assignment to display the current iris, gain,
shutter speed, and zoom position status of the
target camera on the LCD panel for about three
seconds.
Note
This function is not supported for the ILME-FR7.
After approximately three seconds, the display
a
utomatically turns off.
ZOOM position indicator
 represents the divisions between the WIDE
a
nd TELE positions, while  represents the
curre
nt position from the WIDE end.
 indicates Clear Image Zoom and the digital
zoom
range. The indicator changes from  to 
wh
en the camera zoom is in that range.
Restoring Factory
Default Settings
You can restore all settings stored in the unit to
their factory default values.
This operation is performed using MAINTENANCE
>R
ESET in the RM menu.
1 Press the RM MENU button, turning it on
(button is lit yellow).
The RM menu top menu appears.
2 Turn the SELECT knob to move the cursor
to MAINTENANCE.
3 Press the SELECT button.
The MAINTENANCE menu appears.
4 Turn the SELECT knob to select RESET.
The RESET screen appears.
5 Turn the SELECT knob to move the cursor
to RESET ALL.
 
    
6 Turn the VALUE knob to change NOT EXEC
to EXEC, then press the VALUE button.
The following message appears, prompting
y
ou to reboot the unit.
7 Turn the VALUE knob to change NO to YES,
then press the VALUE button.
The unit reboots automatically.

WIDE TELE

Sony RM-IP500 Specifications

General

Interface	Wired
Product color	Black
Brand compatibility	Sony
Remote control proper use	-
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Built-in display	Yes
Maximum range	- m
I/O ports	RJ-45, D-Sub 15-pin, DC
Rechargeable	No
Harmonized System (HS) code	85299097

Weight and Dimensions

Depth	224.1 mm
Width	306 mm
Height	159.3 mm
Weight	2400 g
