*2 If the WIDE D(VIEW-DR) function exists in EXPOSURE >MODE >FULL AUTO in the camera menu and it is set to a
setting other than OFF, FULL AUTO mode cannot be set to OFF using the AE button. To switch between AUTO and
manual using the AE button, set WIDE D to OFF.
*3 Enabled when Exposure Mode is set to FULL AUTO or BACK LIGHT in the camera menu.
*4 Setting is enabled in the camera menu.
*5 Except for SRG-X400/201M2 and SRG-X120/HD1M2, the APERTURE setting of the PICTURE menu on the camera is
app
lied.
*6 GAIN Pri cannot be selected.
*7 Setting changes with the frame rate (50 Hz/59.94 Hz). Set CONFIG >RM SETUP >CAMERA FREQ in the RM menu to the
f
rame rate setting of the camera.
*8 Target cameras: BRC-X1000, BRC-H800, and BRC-H780 with firmware version 2.0 or later
*9 Target cameras: BRC-X1000 and BRC-H800 with firmware version 2.0 or later
*10 On the BRC-X400/X401, GAIN Pri cannot be selected.
*11 Target cameras: SRG-X400/201M2
*12 Target cameras: BRC-X400/X401
ILME-FR7
Control block Button/knob Function Conditions
Lens control block AE button Exposure mode selection When the button is on (lit): Follows CONFIG
>R
M SETUP >AE CONFIG setting in the RM
menu.
When the button is off (not lit): Manual.
FOCUS adjustment knob Manual focus adjustment –
AF/MF button Focus adjustment mode
se
lection
–
Push AF/MF button Temporary focus
a
djustment mode change
When the AF/MF button is on (lit): Auto
focus stops while the button is pressed.
When the AF/MF button is off (not lit): Auto
f
ocus operates while the button is pressed.
ND FILTER/IRIS knob Iris value or ND filter value
ad
justment
Iris value adjustment when CONFIG >SW
ASSIGN >IRIS KNOB is set to IRIS in the RM
menu.
ND filter value adjustment when set to ND
FILT
ER.
Color adjustment
bloc
k
WB SET button One-push white balance
auto adjustment
Enabled when OPERATION >WHITE >WB
MODE is set to MEM.A T/T or MEM.A R/B in
the RM menu.
REC START/STOP button Start/stop recording. When the button is off (not lit): Start
r
ecording.
When the button is on (
lit): Stop recording.
BARS button Toggle color bars output
on
/off.
–
ASSIGN 1 to ASSIGN 3
bu
ttons
Toggle backlight
compensation on/off.
Enabled when the AE button is lit.
Camera assignable
but
tons 1 to 9
–
FOCUS HOLD lens
assigna
ble button
–
Display switch –
Color temperature/R-
WH
ITE knob and tint/B-
WHITE knob
Color temperature and
tint adjustment
R gain and B gain
ad
justment
When OPERATION >WHITE >WB MODE is
se
t to MEM-A T/T or ATW in the RM menu,
color temperature and tint adjustment is
enabled.
When set to MEM-A R/B, R gain and B gain
ad
justment is enabled.
When set to PRESET, color temperature
adju
stment only is enabled.
Tint cannot be adjusted.
