Operation using ASSIGN 4, ASSIGN
5, and ASSIGN 6
Press ASSIGN 4, ASSIGN 5, or ASSIGN 6. The
button is lit yellow, and the adjustment item and
setting of the function assigned to the button is
displayed on the LCD panel.
For details about function assignments to assign
bu
ttons, see “Assigning Functions to Assign
Buttons” (page 51).
Setting Specific
Functions using
Shortcuts (ILME-FR7)
When the IRIS, GAIN, SHUTTER, ASSIGN 4,
ASSIGN 5, or ASSIGN 6 button is pressed on the
menu control block, the setup item and setting
of the function assigned to the button is
displayed on the LCD panel or camera image.
You can change the setting using the VALUE
knob (FUNCTION menu or multi-function dial
mode).
This allows you to set some functions more
q
uickly than by using normal menu operations.
Note
To use functions displayed on the camera image,
set the camera to superimpose the screen
display on the image output used for operating
this unit.
*1 Picture profile is not supported on the ILME-FR7.
Target buttons/functions LCD display Setting
d
isplay
destination
Dedicated
but
tons
Iris IRIS Camera
ISO/gain ISO/GAIN Camera
ima
ge
Shutter SHUTTER Camera
ima
ge
ASSIGN 4 to
AS
SIGN 6
buttons
*1
DETAIL level DETAIL
LEVEL
LCD panel
Knee point KNEE LCD panel
Exposure
co
mpensation
AE LEVEL Camera
ND filter ND FILTER Camera
ima
ge
Audio input
lev
el
AUDIO LVL LCD panel
Camera
assigna
ble
button
ASSIGN 1 to
AS
SIGN 9
Camera
Lens FOCUS
HO
LD button
FOCUS
HOLD
Camera

Sony RM-IP500 Specifications

General

Interface	Wired
Product color	Black
Brand compatibility	Sony
Remote control proper use	-
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Built-in display	Yes
Maximum range	- m
I/O ports	RJ-45, D-Sub 15-pin, DC
Rechargeable	No
Harmonized System (HS) code	85299097

Weight and Dimensions

Depth	224.1 mm
Width	306 mm
Height	159.3 mm
Weight	2400 g
