Sony RM-IP500 User Manual

70
KNEE MODE
POINT
Adjusts KNEE POINT.
SLOPE
Adjusts the gradient of the slope above the knee
point (degree of compression).
MATRIX
Sets the MATRIX adjustment function on the
target camera.
MATRIX
Turns the MATRIX adjustment function on/off.
When set to ON, you can enhance or weaken a
specific color region while keeping the white
convergence point unchanged.
SELECT
Selects a built-in preset matrix used for matrix
calculation. You can choose from STD, HIGH SAT,
and FL LIGHT.
OTHER
Sets the speed of movement when switching
positions using preset memory. Used to make
other settings on the target camera.
PRST SPEED
Sets the speed of movement when switching
positions using preset memory.
For an ILME-FR7 target camera, a value that is
dou
ble the value selected here is applied when
the Speed Step setting for pan/tilt is set to
Extended on the camera.
CIZ
Turns the Clear Image Zoom function of the
target camera on/off.
TELE CONV
Magnifies the image two times using the
teleconvertor function of the target camera.
Settings Description
AUTO Automatically calculates the optimum
luminance level at which knee correction
is applied from the luminance level of the
image being shot.
MANUAL Allows you to adjust the luminance level at
which knee correction (POINT and SLOPE)
is applied, irrespective of the luminance
level of the image being shot.
Settings Description
OFF Magnification function is not used.
ON Magnification function is used.

Sony RM-IP500 Specifications

General

Interface	Wired
Product color	Black
Brand compatibility	Sony
Remote control proper use	-
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Built-in display	Yes
Maximum range	- m
I/O ports	RJ-45, D-Sub 15-pin, DC
Rechargeable	No
Harmonized System (HS) code	85299097

Weight and Dimensions

Depth	224.1 mm
Width	306 mm
Height	159.3 mm
Weight	2400 g
