Suzuki 2005 GSF1200 User Manual

General Information: 0A-10
Chassis
Electrical
Capacities
Item Specification Remark
Front suspension Telescopic, coil spring, oil damped
Rear suspension Link type, coil spring, oil damped
Front suspension stroke 130 mm (5.1 in)
Rear wheel travel 136 mm (5.4 in)
Caster 35° (right & left)
Trail 25° 20’
Steering angle 104 mm (4.10 in)
Turning radius 2.8 m (9.2 ft)
Front brake Disc brake, twin
Rear brake Disc brake
Front tire size 120/70ZR17M/C (58W), tubeless
Rear tire size 180/55ZR17M/C (73W), tubeless
Item Specification Remark
lgnition type Electronic ignition (Transistorized)
lgnition timing
7° B.T.D.C. at 1 300 r/min E-28
7° B.T.D.C. at 1 200 r/min Others
Spark plug NGK JR9B
Battery 12 V 36 kC (10 Ah)/10 HR
Generator Three-phase A.C. generator
Main fuse 30 A
Fuse 10/10/15/15/10 A
Headlight
12 V 60/55 W (H4) GSF1200
12 V 55 W (H7) + 12 V 55 W (H7) GSF1200S
Position light
12 V 5 W GSF1200
12 V 5W x 2 GSF1200S
Turn signal light 12 V 21 W x 4
Brake light/Taillight 12 V 21/5 W
License plate light 12 V 5 W
Speedometer light LED
Tachometer light LED
Neutral indicator light LED
High beam indicator light LED
Turn signal indicator light LED
Oil pressure indicator light LED
Item Specification Remark
Fuel tank Including reserve 20.0 L (5.3/4.4 US/lmp gal)
Engine oil
Reserve 4.4 L (1.2/1.0 US/lmp gal)
Oil change 3 300 ml (3.4/2.9 US/lmp qt)
With filter change 3 500 ml (3.6/3.0 US/lmp qt)
Overhaul 4 600 ml (4.9/4.0 US/lmp qt)

Suzuki 2005 GSF1200 Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (transistorized)
Lubrication	Wet sump
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	790 mm (31.1 in)
Ground Clearance	135 mm (5.3 in)
Engine Type	4-stroke, 4-cylinder, DOHC
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Fuel Tank Capacity	20.0 L (5.3 US gal)
Overall Length	2, 140 mm (84.3 in)
Overall Width	790 mm (31.1 inches)
