9D-4 Exterior Parts:
Frame Cover Cushion Construction
B649G19406002
1
2
4
2
1
FWD
FWD
3
3
“A”
I649G1940031-02
1. Front fender 3. Washer “A”: Before installing the front fender, apply an adhesive agent
to the inside of the washer to prevent it from falling.
2. Fender plate nut 4. Front fork
2
1
2
I649G1940004-02
1. Frame cover 2. Cushion
