Suzuki 2005 GSF1200 User Manual

Charging System: 1J-16
Specifications
Service Data
B649G11A07001
Battery
CAUTION
!
Never use anything except the specified battery.
Generator
Tightening Torque Specifications
B649G11A07002
NOTE
The specified tightening torque is also described in the following.
“Generator Components: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque Specifications: in Section
0C”.
Item Specification Note
Type designation FT12A-BS
Capacity 12V, 36.0 kC (10 Ah)/10HR
Standard electrolyte S.G. 1.320 at 20 °C (68 °F)
Item Specification Note
Generator maximum output More than 550 W at 5 000 r/min.
Regulated voltage 13.5 – 15 V at 5 000 r/min.
Generator
Slip ring O.D. Limit: 14.0 (0.55)
DENSO
Brush length Limit: 4.5 (0.18)
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Generator mounting bolt 25 2.5 18.0 )
Bearing retainer screw 2.5 0.25 1.8 )
Generator housing nut 4.5 0.45 3.25 )
Generator driven gear nut 55 5.5 4.0 )

Suzuki 2005 GSF1200 Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (transistorized)
Lubrication	Wet sump
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	790 mm (31.1 in)
Ground Clearance	135 mm (5.3 in)
Engine Type	4-stroke, 4-cylinder, DOHC
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Fuel Tank Capacity	20.0 L (5.3 US gal)
Overall Length	2, 140 mm (84.3 in)
Overall Width	790 mm (31.1 inches)
