Suzuki 2005 GSF1200 User Manual

Rear Brakes: 4C-9
Specifications
Service Data
B649G14307004
Brake
Unit: mm (in)
Oil
Tightening Torque Specifications
B649G14307005
NOTE
The specified tightening torque is also described in the following.
“Rear Brake Components: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque Specifications: in Section
0C”.
Item Standard Limit
Brake disc thickness Rear 4.8 – 5.2 (0.189 – 0.205) 4.5 (0.18)
Brake disc runout — 0.30 (0.012)
Brake caliper cylinder bore Rear 38.180 – 38.256 (1.5031 – 1.5061) —
Brake caliper piston diameter Rear 38.098 – 38.148 (1.4999 – 1.5019) —
Item Specification Note
Brake fluid type DOT 4
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Rear brake caliper mounting bolt 22 2.2 16.0 )
Rear brake pad mounting pin 18 1.8 13.0 )
Pad pin plug 2.5 0.25 1.8 )
Rear brake caliper sliding pin 27 2.7 19.5 ) / )
Brake hose union bolt 23 2.3 16.5 )
Brake disc bolt 23 2.3 16.5 )

Suzuki 2005 GSF1200 Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (transistorized)
Lubrication	Wet sump
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	790 mm (31.1 in)
Ground Clearance	135 mm (5.3 in)
Engine Type	4-stroke, 4-cylinder, DOHC
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Fuel Tank Capacity	20.0 L (5.3 US gal)
Overall Length	2, 140 mm (84.3 in)
Overall Width	790 mm (31.1 inches)
