Suzuki 2005 GSF1200 User Manual

Brake Control System and Diagnosis: 4A-7
6) Loosen the air bleeder valve and pump the brake
lever until the old brake fluid flows out of the brake
system.
7) Close the air bleeder valve and disconnect the clear
hose.
8) Fill the reservoir with new brake fluid to the upper
line of the reservoir.
Tightening torque
Air bleeder valve (Front brake) (a): 7.5 N·m (0.75
kgf-m, 5.5 lb-ft)
Rear Brake
1) Place the motorcycle on a level surface.
2) Remove the right frame cover. Refer to “Exterior
Parts Removal and Installation: in Section 9D”.
3) Remove the brake fluid reservoir cap and
diaphragm.
4) Suck up the old brake fluid as much as possible.
5) Fill the reservoir with new brake fluid.
BF: Brake fluid (DOT 4)
6) Connect a clear hose to the air bleeder valve and
insert the other end of the hose into a receptacle.
7) Loosen the air bleeder valve and pump the brake
pedal until the old brake fluid flows out of the brake
system.
8) Close the air bleeder valve and disconnect the clear
hose.
9) Fill the reservoir with new brake fluid to the upper
line of the reservoir.
Tightening torque
Air bleeder valve (Rear brake) (a): 6.0 N·m (0.6 kgf-
m, 4.5 lb-ft)
I649G1410010-01
(a)
(a)
I649G1410042-01
I649G1410011-01
I649G1410012-01
I649G1410013-01
(a)
I649G1410043-01

Suzuki 2005 GSF1200 Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (transistorized)
Lubrication	Wet sump
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	790 mm (31.1 in)
Ground Clearance	135 mm (5.3 in)
Engine Type	4-stroke, 4-cylinder, DOHC
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Fuel Tank Capacity	20.0 L (5.3 US gal)
Overall Length	2, 140 mm (84.3 in)
Overall Width	790 mm (31.1 inches)
