Suzuki GSX-R600 User Manual

Engine Mechanical: 1D-5
Engine Right Side
Item Removal Inspection Installation
Exhaust pipes/Muffler
Refer to “Exhaust Pipe /
Muffler Removal and
Installation in Section 1K
(Page 1K-11)”.
Refer to “Exhaust System
Inspection in Section 1K
(Page 1K-14)”.
Refer to “Exhaust Pipe /
Muffler Removal and
Installation in Section 1K
(Page 1K-11)”.
Cam chain tension adjuster
Refer to “Engine Top Side
Disassembly (Page 1D-25)”.
Refer to “Cam Chain Tension
Adjuster Inspection
(Page 1D-36)”.
Refer to “Engine Top Side
Assembly (Page 1D-27)”.
Clutch cover
Refer to “Clutch Removal in
Section 5C (Page 5C-5)”.
—
Refer to “Clutch Installation
in Section 5C (Page 5C-7)”.
Clutch plates
Refer to “Clutch Removal in
Section 5C (Page 5C-5)”.
Refer to “Clutch Parts
Inspection in Section 5C
(Page 5C-11)”.
Refer to “Clutch Installation
in Section 5C (Page 5C-7)”.
Clutch sleeve hub
Refer to “Clutch Removal in
Section 5C (Page 5C-5)”.
—
Refer to “Clutch Installation
in Section 5C (Page 5C-7)”.
Primary driven gear
Refer to “Clutch Removal in
Section 5C (Page 5C-5)”.
Refer to “Clutch Parts
Inspection in Section 5C
(Page 5C-11)”.
Refer to “Clutch Installation
in Section 5C (Page 5C-7)”.
Oil pump drive sprocket
Refer to “Engine Bottom
Side Disassembly (Page 1D-
47)”.
—
Refer to “Engine Bottom
Side Assembly (Page 1D-
54)”.
Gearshift shaft
Refer to “Gearshift Shaft /
Gearshift Cam Plate
Removal and Installation in
Section 5B (Page 5B-16)”.
Refer to “Gearshift Linkage
Inspection in Section 5B
(Page 5B-18)”.
Refer to “Gearshift Shaft /
Gearshift Cam Plate
Removal and Installation in
Section 5B (Page 5B-16)”.
CKP sensor rotor/Cam
chain drive sprocket
Refer to “Engine Bottom
Side Disassembly (Page 1D-
47)”.
—
Refer to “Engine Bottom
Side Assembly (Page 1D-
54)”.
Cam chain tensioner
Refer to “Engine Bottom
Side Disassembly (Page 1D-
47)”.
Refer to “Cam Chain
Tensioner Inspection
(Page 1D-37)”.
Refer to “Engine Bottom
Side Assembly (Page 1D-
54)”.
CKP sensor
Refer to “CKP Sensor
Removal and Installation in
Section 1C (Page 1C-3)”.
Refer to “CKP Sensor
Inspection in Section 1C
(Page 1C-3)”.
Refer to “CKP Sensor
Removal and Installation in
Section 1C (Page 1C-3)”.

Suzuki GSX-R600 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC
Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.9:1
Fuel System	Fuel injection
Starter	Electric
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Engine Displacement	599cc
Transmission	6-speed, constant mesh
Front Tire Size	120/70ZR17M/C (58W)
Rear Tire Size	180/55ZR17M/C (73W)
Overall Length	2030 mm
Overall Width	710 mm
Seat Height	810 mm
Ground Clearance	130 mm
Curb Weight	187 kg
Fuel Tank Capacity	17.0 L
