1G-14 Fuel System:
Specifications
Service Data
B837H11707001
Injector + Fuel Pump + Fuel Pressure Regulator
Fuel
Tightening Torque Specifications
B837H11707002
NOTE
The specified tightening torque is also described in the following.
“Fuel Pump Components (Page 1G-10)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Item Specification Note
Injector resistance 11 – 13 Ω at 20 °C (68 °F)
Fuel pump discharge amount 167 ml (5.6/5.9 US/lmp oz) and more/10 sec.
Fuel pressure regulator operating
set pressure
Approx. 300 kPa (3.0 kgf/cm
2
, 4.3 psi)
Item Specification Note
Fuel type
Use only unleaded gasoline of at least 87 pump octane (R/2
+ M/2).
Gasoline containing MTBE (Methyl Tertiary Butyl Ether), less
than 10% ethanol, or less than 5% methanol with
appropriate cosolvents and corrosion inhibitor is permissible.
E-03, 28, 33
Gasoline used should be graded 91 octane (Research
Method) or higher. Unleaded gasoline is recommended.
Others
Fuel tank capacity
Including
reserve
16 L (4.2/3.5 US/lmp gal) E-33
17 L (4.5/3.7 US/lmp gal) Others
Fuel level
indicator light
lighting
Approx. 3.5 L (0.9/0.8 US/lmp gal)
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Fuel pump mounting bolt 10 1.0 7.0 )(Page 1G-13)

Suzuki GSX-R600 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC
Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.9:1
Fuel System	Fuel injection
Starter	Electric
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Engine Displacement	599cc
Transmission	6-speed, constant mesh
Front Tire Size	120/70ZR17M/C (58W)
Rear Tire Size	180/55ZR17M/C (73W)
Overall Length	2030 mm
Overall Width	710 mm
Seat Height	810 mm
Ground Clearance	130 mm
Curb Weight	187 kg
Fuel Tank Capacity	17.0 L
