Suzuki GSX-R600 User Manual

2D-10 Wheels and Tires:
Rear Wheel Assembly Construction
B837H12406007
LH RH
(a)
1
(b)
2
(c)
3
“a”
I837H1240039-03
1. Rear sprocket nut “a”: Clearance : 35 N⋅m (3.5 kgf-m, 25.5 lb-ft)
2. Rear axle nut : 60 N⋅m (6.0 kgf-m, 43.0 lb-ft) : Apply grease.
3. Brake disc bolt : 100 N⋅m (10 kgf-m, 72.5 lb-ft) : Apply thread lock to the thread part.

Suzuki GSX-R600 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC
Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.9:1
Fuel System	Fuel injection
Starter	Electric
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Engine Displacement	599cc
Transmission	6-speed, constant mesh
Front Tire Size	120/70ZR17M/C (58W)
Rear Tire Size	180/55ZR17M/C (73W)
Overall Length	2030 mm
Overall Width	710 mm
Seat Height	810 mm
Ground Clearance	130 mm
Curb Weight	187 kg
Fuel Tank Capacity	17.0 L
