1H-13 Ignition System:
Specifications
Service Data
B837H11807001
Electrical
Unit: mm (in)
Tightening Torque Specifications
B837H11807002
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Item Specification Note
Firing order 1 ⋅ 2 ⋅ 4 ⋅ 3
Spark plug
Type
NGK: CR9EIA-9
DENSO: IU27D
Gap 0.8 – 0.9 (0.031 – 0.035)
Spark performance Over 8 (0.3) at 1 atm.
CKP sensor resistance 142 – 194 Ω
CKP sensor peak voltage 0.28 V and more When cranking
Ignition coil resistance
Primary 1.1 – 1.9 Ω
Terminal –
Ter m in al
Secondary 6.4 – 9.6 kΩ
Plug cap –
Ter m in al
Ignition coil primary peak voltage 80 V and more When cranking
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Spark plug 11 1.1 8.0 )(Page 1H-6)
