Suzuki GSX-R600 User Manual

1K-15 Exhaust System:
Specifications
Tightening Torque Specifications
B837H11B07001
NOTE
The specified tightening torque is also described in the following.
“Exhaust Control System Construction (Page 1K-4)”
“Exhaust System Components (Page 1K-5)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Special Tools and Equipment
Recommended Service Material
B837H11B08001
NOTE
Required service material is also described in the following.
“Exhaust System Components (Page 1K-5)”
Special Tool
B837H11B08002
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
EXCVA pulley mounting bolt 5 0.5 3.5 )(Page 1K-9)
HO2 sensor 25 2.5 18.0 )(Page 1K-13)
Exhaust pipe bolt 23 2.3 16.5 )(Page 1K-13)
Exhaust pipe mounting bolt 23 2.3 16.5 )(Page 1K-13)
EXCV cable mounting nut 5.5 0.55 4.0 )(Page 1K-14)
Muffler mounting nut 25 2.5 18.0 )(Page 1K-14)
Muffler connecting bolt 23 2.3 16.5 )(Page 1K-14)
Material SUZUKI recommended product or Specification Note
Muffler seal MUFFLER SEAL LOCTITE 5920
(commercially available) or
equivalent
— )(Page 1K-14)
09900–25008 09900–25009
Multi-circuit tester set Needle pointed probe set
)(Page 1K-10) /
)(Page 1K-11)
)(Page 1K-10) /
)(Page 1K-11)
09930–82720
Mode select switch
)(Page 1K-6) / )(Page 1K-
8)

Suzuki GSX-R600 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC
Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.9:1
Fuel System	Fuel injection
Starter	Electric
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Engine Displacement	599cc
Transmission	6-speed, constant mesh
Front Tire Size	120/70ZR17M/C (58W)
Rear Tire Size	180/55ZR17M/C (73W)
Overall Length	2030 mm
Overall Width	710 mm
Seat Height	810 mm
Ground Clearance	130 mm
Curb Weight	187 kg
Fuel Tank Capacity	17.0 L
