4A-8 Brake Control System and Diagnosis:
8) Fill the reservoir with brake fluid to the upper mark of
the reservoir.
9) Install the reservoir cap.
Rear Brake
1) Place the motorcycle on a level surface.
2) Remove the brake fluid reservoir tank mounting bolt.
3) Remove the brake fluid reservoir cap and
diaphragm.
4) Suck up the old brake fluid as much as possible.
5) Fill the reservoir with new brake fluid.
BF: Brake fluid (DOT 4)
6) Connect a clear hose to the air bleeder valve and
insert the other end of the hose into a receptacle.
7) Loosen the air bleeder valve and pump the brake
pedal until the old brake fluid flows out of the brake
system.
8) Close the air bleeder valve (1) and disconnect the
clear hose.
Tightening torque
Air bleeder valve (Rear) (a): 7.5 N·m (0.75 kgf-m,
5.5 lb-ft)
I837H1410017-01
I837H1410018-01
I837H1410019-01
I837H1410020-01
(a)
1
I837H1410021-01

Suzuki GSX-R600 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC
Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.9:1
Fuel System	Fuel injection
Starter	Electric
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Engine Displacement	599cc
Transmission	6-speed, constant mesh
Front Tire Size	120/70ZR17M/C (58W)
Rear Tire Size	180/55ZR17M/C (73W)
Overall Length	2030 mm
Overall Width	710 mm
Seat Height	810 mm
Ground Clearance	130 mm
Curb Weight	187 kg
Fuel Tank Capacity	17.0 L
