4A-8 Brake Control System and Diagnosis:
Front Brake Master Cylinder Components
BA02J24106008
1
2
3
(a)
4
(b)
(b)
FWD
FWD
IA02J1410043-01
1. Reservoir cap 4. Front brake hose : Do not reuse.
2. Diaphragm : 10 Nâ‹…m (1.0 kgf-m, 7.0 lbf-ft)
3. Piston/cup set : 23 Nâ‹…m (2.3 kgf-m, 16.5 lbf-ft)
