Page #91 background image
Engine General Information and Diagnosis: 1A-22
Visual Inspection
Prior to diagnosis using the FI indicator light assy or SDS, perform the following visual inspections. The reason for
visual inspection is that mechanical failures (such as oil leakage) cannot be displayed on the screen with the use of FI
indicator light assy or SDS.
Engine oil level and leakage. Refer to “Engine Oil Filter Replacement” in Section 0B (Page 0B-7).
Engine coolant level and leakage. Refer to “Cooling Circuit Inspection” in Section 1F (Page 1F-4).
Fuel level and leakage. Refer to “Fuel Hose Inspection” in Section 0B (Page 0B-14).
Clogged air cleaner element. Refer to “Air Cleaner Element Cleaning” in Section 0B (Page 0B-4).
Battery condition.
Throttle cable play. Refer to “Throttle Cable Play Inspection and Adjustment” in Section 0B (Page 0B-12).
Broken fuse.
Exhaust gas leakage and noise. Refer to “Exhaust System Inspection” in Section 1K (Page 1K-3).
Each coupler disconnection.
Clogged radiator fins. Refer to “Radiator Inspection and Cleaning” in Section 1F (Page 1F-4).
Malfunction Code and Defective Condition Table
BA02J21104009
DTC No. Detected Item Detected Failure Condition Check For
12
CKP sensor
The signal does not reach ECM for 1 sec. or
more, after receiving the IAP sensor input
signal.
CKP sensor wiring and
mechanical parts.
CKP sensor, lead wire/coupler
connection.
P0335
14
TP sensor
The sensor should produce following voltage.
0.5 V sensor voltage < 4.8 V
In other than the above range, 14 (P0120) is
indicated.
TP sensor, lead wire/coupler
connection.
P0120
H Sensor voltage is higher than specified value.
TP sensor circuit shorted to
VCC or ground circuit open.
L Sensor voltage is lower than specified value.
TP sensor circuit open or
shorted to the ground or VCC
circuit open.
15
ECT sensor
The sensor voltage should be the following.
0.1 V sensor voltage < 4.8 V
In other than the above range, 15 (P0115) is
indicated.
ECT sensor, lead wire/coupler
connection.
P0115
H Sensor voltage is higher than specified value.
ECT sensor circuit open or
ground circuit open.
L Sensor voltage is lower than specified value.
ECT sensor circuit shorted to
the ground.
17
IAP sensor
The sensor should produce following voltage.
0.5 V sensor voltage < 4.4 V
In other than the above range, 17 (P0105) is
indicated.
IAP sensor, lead wire/coupler
connection.
P0105
H Sensor voltage is higher than specified value.
IAP sensor circuit shorted to
VCC or ground circuit open.
L Sensor voltage is lower than specified value.
IAP sensor circuit open or
shorted to ground or VCC
circuit open.
21
IAT sensor
The sensor voltage should be the following.
0.2 V sensor voltage < 4.8 V
In other than the above range, 21 (P0110) is
indicated.
IAT sensor, lead wire/coupler
connection.
P0110
H Sensor voltage is higher than specified value.
IAT sensor circuit open or
ground circuit open.
L Sensor voltage is lower than specified value.
IAT sensor circuit shorted to
the ground.
