Toro Groundsmaster 4500-D Series User Manual

TwoSpeedShiftManifold
g308769
Figure108
1.Twospeedshiftmanifold
6.Hydraulictube
11.O-ring
2.Capscrew(2used)7.O-ring12.O-ring
3.Flangenut(2used)
8.Hydraulictube13.Hydraulictube
4.Reartractioncontrolmanifold9.O-ring
5.Liftcircuitjunctionmanifold
10.Hydraulictube
Note:Theportsonthetwospeedshiftmanifoldaremarkedforeasyidentication
ofcomponents.RefertotheAppendixA(pageA–1).
Removal(Figure108)
1.ReadtheGeneralPrecautionsforRemovingandInstallingHydraulicSystem
Components(page5–87).
2.Topreventcontaminationofhydraulicsystemduringmanifoldremoval,
thoroughlycleanexterioroftwospeedshiftmanifold.
3.Labelallhydrauliclinesforassemblypurposes.
Groundsmaster
®
4500-D/4700-D
Page5–113
HydraulicSystem:ServiceandRepairs
19245SLRevA
