ResistorAssembly
1
2
g276036
Figure224
1.Resistorassembly
2.Endofresistorbody
Theenginewireharnessalsocontainsa1.6Kohmresistorthatisnecessaryfor
ignitionswitchoperation.Theresistorplugsintothewiringharnessnearthe
enginestartermotor(seeAppendixA(pageA–1)).
Theresistorassembliescanbeidentiedbytheirgraycolor,resistorsymboland
Toropartnumberontheendoftheresistorassemblybody.
Testing
Theresistorcanbetestedusingadigitalmultimeter(ohmssetting).The
resistanceacrosstheresistorterminalsshouldbe1.6Kohms.
ElectricalSystem:ComponentTesting
Page6–64
Groundsmaster
®
4500-D/4700-D
19245SLRevA
