Toro Groundsmaster 4500-D Series User Manual

Adjustments
TractionPedalAdjustment
g309420
Figure179
1.Tractionpedal4.Rodendbearing
2.Pedalpositionsensor
5.Springshaft
3.Hexnut
6.Springshafthex
Thetractionpedalincludesaneutralassemblythatisusedtoadjustthetraction
neutralposition(Figure179).Tractionpedaladjustmentmaybenecessaryto
makesurethattractionpedalmovementprovidesthecorrectfullreverseandfull
forwardpositionsforthetractionpedalpositionsensor.TheInfoCenterdisplay
canbeusedtochecktractionpedaladjustmentusingthefollowingprocedure.
1.Parkmachineonalevelsurface,lowercuttingdecks,engageparkingbrake
andstopengine.
2.TurnignitionswitchtoRUNbutdonotstartengine.
Traction Pedal
Sensor: 2.407V
g309421
Figure180
3.UsetheInfoCenterDisplayDiagnosticsmenu(seeInfoCenterDisplay(page
6–8))toobtainandselecttheTractionPedalmenuitem.ChooseInputsand
theInfoCenterdisplayshouldidentifysensorvoltage(Figure180).
4.Movetractionpedalfromfullreversetofullforwardpositionswhilenotingthe
rangeofvoltagedisplayedontheInfoCenter.
Groundsmaster
®
4500-D/4700-D
Page6–19
ElectricalSystem:Adjustments
19245SLRevA
