TractionPedalPositionSensorCalibration
g309423
Figure182
1.Tractionpedal2.Pedalpositionsensor
IMPORTANT
Aproperlyinstalledandcalibratedtractionpedalpositionsensoris
criticaltoaccuratetractionsystemresponseandforreliablesensor
life.Usecarewhenremoving,installingandcalibratingthetraction
pedalpositionsensor.
CalibrationofthetractionpedalpositionsensorensuresthattheTECcontroller
canidentifythetractionneutral,forwardandreversepositions.
1.Parkmachineonalevelsurface,lowercuttingdecks,engageparkingbrake
andstopengine.
2.TurnignitionswitchtoRUNbutdonotstartengine.
3.UsetheInfoCenterDisplaySettingsmenu(seeInfoCenterDisplay(page
6–8))toobtainandselectProtectedMenus.EntervalidPINforthemachine
toallowaccesstoprotectedmenuitemsincludingcalibrationofthetraction
pedalpositionsensor.TheInfoCenterdisplayscreenshouldindicatePINin
theupperrighthandcornerwhenthecorrectPINnumberhasbeenentered.
Groundsmaster
®
4500-D/4700-D
Page6–21
ElectricalSystem:Adjustments
19245SLRevA
