IdentifyingtheFastener
g206088
Figure5
InchSeriesBoltsandScrews
1.Grade12.Grade53.Grade8
g206089
Figure6
MetricBoltsandScrews
1.Class8.82.Class10.9
FastenerswithaLockingFeature
IMPORTANT
Ifafastenerwithalockingfeatureorpreviouslyappliedthread
lockingcompoundisreused,cleanthefastenerthreadsandapply
newthreadlockertothefastenerduringinstallation.
Lockingfeaturesaredesignedtocreatefrictionandpreventafastenerfrom
loosening.Lockingfeaturescanbefoundonexternallyorinternallythreaded
fasteners.Commonexamplesareplasticinsertsincorporatedintothefastener
andpre-applied“dry”threadlockingcompound.Keepinmind,afastenerwith
alockingfeatureusuallymeanstherewillbefrictionduringinitialinstallation
andduringremoval.
Tororecommendsreplacingfastenerswithalockingfeatureoncetheyhave
beenremovedbecausetheeffectivenessofthelockingfeaturediminisheswith
eachreuse.Ifitisnecessarytoreuseafastenerwithalockingfeature;applya
threadlockingcompound(Loctiteforexample)tothefastenerduringinstallation.
Usetheappropriatestrengthandtypeofthreadlockingcompoundbasedon
application,fastenersizeorinformationfoundintheproductOperatorsManual,
ServiceManualorInstallationInstructions.
SpecicationsandMaintenance:TorqueSpecications
Page2–10
Groundsmaster
®
4500-D/4700-D
19245SLRevA
