Toro Groundsmaster 4500-D Series User Manual

CuttingDeckMotor
1
2
1
g308862
Figure117
1.Socketheadscrew
2.Hydraulicmotor
Thehydraulicmotorsusedonallcuttingdecksarethesame.
Removal
1.Parkmachineonalevelsurface,lowercuttingdecks,stopengine,engage
parkingbrakeandremovekeyfromtheignitionswitch.
2.ReadtheGeneralPrecautionsforRemovingandInstallingHydraulicSystem
Components(page5–87).
3.Topreventcontaminationofhydraulicsystemduringdeckmotorremoval,
thoroughlycleanexteriorofmotor.
4.Disconnecthydrauliclinesfromdeckmotor.Putcapsorplugsonttingsand
hosestopreventcontaminationofhydraulicsystem.Labelhydrauliclines
forproperassembly.
2
1
3
g308391
Figure118
1.FlowIN
3.Casedrain
2.FlowOUT
5.Removetwo(2)socketheadscrewsandatwashersthatsecurehydraulic
motortocuttingdeck(Figure117).
6.Lifthydraulicmotorfromcuttingdeck.
Groundsmaster
®
4500-D/4700-D
Page5–123
HydraulicSystem:ServiceandRepairs
19245SLRevA
