BrakeInspectionandRepair
3
2
4
5
6
7
8
9
10
14
13
12
11
15
1
g276542
Figure234
1.Brakehousing(LHshown)6.Hitchpin(2used)
11.Rotatingactuator
2.Seal7.Stationarydisc(4used)12.Extensionspring(3used)
3.Pullrod
8.Rotatingdisc(3used)13.Ball(3used)
4.Clevispin(2used)
9.Retainingring14.Plug
5.Link(2used)10.Gasket15.O−ring
BrakeInspectionandRepair(Figure234)
1.Scrapegasketmaterial(item10)frombrakehousingandplanetarydrive
mountingsurfaces.
2.Removeretainingring(item9)frombrakehousinggroove.
3.Removestationarydiscs(item7)androtatingdiscs(item8).
4.Removeextensionsprings(item12).
5.Removeactuatorassembly(items11,6,5,4and3)andballs(item13).
6.Removeseal(item2)frombrakehousing.
7.Washpartsincleaningsolvent.Inspectcomponentsforwearordamage.
8.Reversesteps2through6toassemblebrakes,installingnewpartsas
necessary.Installanewseal(item2).
9.Useanewgasket(item10)wheninstallingbrakeassemblytomachine.
Groundsmaster
®
4500-D/4700-D
Page7–7
Axles,PlanetariesandBrakes:ServiceandRepairs
19245SLRevA
